Chevrolet: 400 Small Block 23 Degree (Heavy Duty): – Flat Top: 1.568 C/H – 4.155 Bore – -4CC – #95455
Application: Recommended for Applications Using Nitrous (Up To 250HP Shot) / Boost (Up To 8LBS)
[Please Note]: [Please Note]: Image is a representation of this item. Actual item may vary.
Piston Top Type: Flat Top
Bore: 4.155
Stroke: 3.48
Rod Length: 5.7
Compression Height: 1.568
Compression Ratio (57):
Dome Volume: -4
Gram Weight: 530
Rings: 1/16 1/16 3/16
Ring Set: N/A
Rings Included: NO
Pin Type: 5115 Straight Wall
Pin Diameter: 0.927
Pin Length: 2.5
Pin Wall: 0.15
Pin Weight: 118 Grams
Block Height: 9.025
Optional Upgrade: (1) Piston Rings Sold Separately. (2) Compression Ratio based on .050 piston to head clearance (deck & gasket combined).
Chevrolet: 400 Small Block 23 Degree (Heavy Duty): – Flat Top: 1.268 C/H – 4.155 Bore – -4CC – #95465
Application: Recommended for Applications Using Nitrous (Up To 250HP Shot) / Boost (Up To 8LBS)
[Please Note]: [Please Note]: Image is a representation of this item. Actual item may vary.
Piston Top Type: Flat Top
Bore: 4.155
Stroke: 3.48
Rod Length: 6
Compression Height: 1.268
Compression Ratio (57):
Dome Volume: -4
Gram Weight: 492
Rings: 1/16 1/16 3/16
Ring Set: N/A
Rings Included: NO
Pin Type: 5115 Straight Wall
Pin Diameter: 0.927
Pin Length: 2.5
Pin Wall: 0.15
Pin Weight: 118 Grams
Block Height: 9.025
Optional Upgrade: (1) Piston Rings Sold Separately. (2) Compression Ratio based on .050 piston to head clearance (deck & gasket combined).
Chevrolet: 400 Small Block 23 Degree (Heavy Duty): – Flat Top: 1.42 C/H – 4.155 Bore – -4CC – #90008
Application: Recommended for Applications Using Nitrous (Up To 250HP Shot) / Boost (Up To 8LBS)
[Please Note]: [Please Note]: Image is a representation of this item. Actual item may vary.
Piston Top Type: Flat Top
Bore: 4.155
Stroke: 3.75
Rod Length: 5.7
Compression Height: 1.42
Compression Ratio (57):
Dome Volume: -4
Gram Weight: 455
Rings: 1/16 1/16 3/16
Ring Set: N/A
Rings Included: NO
Pin Type: 5115 Straight Wall
Pin Diameter: 0.927
Pin Length: 2.5
Pin Wall: 0.15
Pin Weight: 118 Grams
Block Height: 9.025
Optional Upgrade: (1) Piston Rings Sold Separately. (2) Compression Ratio based on .050 piston to head clearance (deck & gasket combined).
